Specifications:

Continuous output power ≥30W aser wavelength 10.6um
Galvanometer deflection High precision Double d scanning system
Engraving speed : ≤7000mm/s
Master control : Highly integrated motherboard with 10 inch screen
Operating system : WIN CE
Cooling System : Air cooling system
Focus lens : Focal length 138 mm
Marking type : Both Dot matrix and vector machine
Minimum line width : 0.03mm
Repositioning Accuracy : 0.01mm
Marking area : 110mm×110mm（Choosable）
Locate mode : Red light focusing
Font : Standard Chinese and English, Numbers, etc
File Format : BMP/DXF/HPGL/JPEG/PLT
Bar codes : CODE39、CODE128、CODE126、QR、
Power: 220V
Power Consumption : 300W Machine net weight 14kg
3 d bracket net weight 30kg
